GIGABYTE B760M AORUS ELITE DDR4
LE 7,750.00
Return within 14 days provided the item is in its original condition
GIGABYTE B760M AORUS ELITE DDR4
The GIGABYTE B760M AORUS ELITE DDR4 is a Micro-ATX B760 board with AORUS styling, DDR4 support, three M.2 slots with thermal guards, 2.5 Gbps LAN and Q-Flash Plus for BIOS updates without a CPU installed.
Specifications
- Socket: LGA 1700
- Chipset: Intel B760
- Form Factor: Micro-ATX
- CPU Support: Intel Core 12th, 13th and 14th Gen
- Memory: 4x DDR4 DIMM, up to 128GB, DDR4-5333 (OC)
- PCIe Slots: 1x PCIe 4.0 x16, 2x PCIe 3.0 x1
- M.2: 3x M.2 (1x PCIe 4.0 x4 CPU, 2x PCIe 4.0 x4 chipset, type 2280)
- SATA: 4x SATA 6Gb/s
- Rear USB: 1x USB-C 3.2 Gen 2, 3x USB 3.2 Gen 1, 2x USB 2.0
- Display Outputs: 1x HDMI 2.1, 2x DisplayPort
- LAN: 2.5 Gbps
- Audio: Realtek HD, 7.1-channel
- Features: M.2 thermal guards, RGB lighting, Q-Flash Plus
- Warranty: 3 Years
Specifications
| Brand | GIGABYTE |
| Model | B760M AORUS ELITE DDR4 |
| Socket | LGA 1700 |
| Chipset | Intel B760 |
| Form Factor | Micro-ATX |
| CPU Support | Intel Core 12th, 13th and 14th Gen |
| Memory | 4x DDR4 DIMM, up to 128GB, DDR4-5333 (OC) |
| PCIe Slots | 1x PCIe 4.0 x16, 2x PCIe 3.0 x1 |
| M.2 | 3x M.2 (1x PCIe 4.0 x4 CPU, 2x PCIe 4.0 x4 chipset, type 2280) |
| SATA | 4x SATA 6Gb/s |
| Rear USB | 1x USB-C 3.2 Gen 2, 3x USB 3.2 Gen 1, 2x USB 2.0 |
| Display Outputs | 1x HDMI 2.1, 2x DisplayPort |
| LAN | 2.5 Gbps |
| Audio | Realtek HD, 7.1-channel |
| Features | M.2 thermal guards, RGB lighting, Q-Flash Plus |
| Warranty | 3 Years |
