MSI MAG B850 GAMING PLUS WIFI PZ
LE 12,000.00
Return within 14 days provided the item is in its original condition
MSI MAG B850 GAMING PLUS WIFI PZ
The MSI MAG B850 GAMING PLUS WIFI PZ is the back-connect Project Zero version of the B850 GAMING PLUS MAX WIFI. All connectors route to the back of the board for a completely clean front, making it ideal for showcase builds. Same full ATX B850 specs including Wi-Fi 7, PCIe 5.0 and 2.5 Gbps LAN.
Specifications
- Socket: AM5
- Chipset: AMD B850
- Form Factor: ATX (Back Connect)
- CPU Support: AMD Ryzen 7000, 8000 and 9000 series
- Memory: 4x DDR5 DIMM, up to 256GB, DDR5-8200 (OC)
- PCIe Slots: 1x PCIe 5.0 x16, 1x PCIe 4.0 x4, 1x PCIe 3.0 x1
- M.2: 4x M.2 (1x PCIe 5.0 x4 CPU, 3x PCIe 4.0 x4 chipset, up to 22110)
- SATA: 4x SATA 6Gb/s
- Rear USB: 1x USB4 Type-C (40Gbps), 1x USB-C 3.2 Gen 2, 4x USB 3.2 Gen 2, 2x USB 2.0
- Display Outputs: 1x HDMI 2.1, 1x DisplayPort 2.1
- LAN: 2.5 Gbps
- Wireless: Wi-Fi 7 (802.11be), Bluetooth 5.4
- Audio: Realtek ALC4080, 7.1-channel
- Features: Back-connect design, M.2 thermal shields, RGB lighting, EZ Debug LED
- Warranty: 3 Years
Specifications
| Brand | MSI |
| Model | MAG B850 GAMING PLUS WIFI PZ |
| Socket | AM5 |
| Chipset | AMD B850 |
| Form Factor | ATX (Back Connect) |
| CPU Support | AMD Ryzen 7000, 8000 and 9000 series |
| Memory | 4x DDR5 DIMM, up to 256GB, DDR5-8200 (OC) |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x4, 1x PCIe 3.0 x1 |
| M.2 | 4x M.2 (1x PCIe 5.0 x4 CPU, 3x PCIe 4.0 x4 chipset, up to 22110) |
| SATA | 4x SATA 6Gb/s |
| Rear USB | 1x USB4 Type-C (40Gbps), 1x USB-C 3.2 Gen 2, 4x USB 3.2 Gen 2, 2x USB 2.0 |
| Display Outputs | 1x HDMI 2.1, 1x DisplayPort 2.1 |
| LAN | 2.5 Gbps |
| Wireless | Wi-Fi 7 (802.11be), Bluetooth 5.4 |
| Audio | Realtek ALC4080, 7.1-channel |
| Features | Back-connect design, M.2 thermal shields, RGB lighting, EZ Debug LED |
| Warranty | 3 Years |
Why Choose it?
